Intel Arc B580

Intel Arc B580
CM4 Functionality Pi 5 Functionality Driver Required? More Info
None Full Yes GitHub Issue

Description and Notes

The Intel Arc B580 is Intel’s second generation standalone graphics card, in the ‘Battlemage’ series. The Xe driver has improved a bit since the first generation ‘Archimedes’ cards, but is still a little rough.

Physically, it requires a x16 PCIe socket. You will need to supply about 225W to the card directly through it’s two 8-pin PCIe power plugs.

Xe Open Source Driver

To get the Xe driver loaded, you have to recompile the Linux kernel for Pi OS on the 6.15 branch (rpi-6.15.y) or later.

Go to Device Drivers > Graphics support on the menuconfig step, and select the Xe driver to install.

Before compiling the kernel, run make menuconfig and set:

  1. Device Drivers > Graphics support > Direct Rendering Manager (XFree86 4.1.0 and higher DRI support) > Intel Xe Graphics
  2. Device Drivers > Graphics support > Direct Rendering Manager (XFree86 4.1.0 and higher DRI support) > Intel Xe Graphics > Force probe xe for selected Intel hardware IDs > * (enter * manually for the value)

There are a few other tweaks that need to be made to get this card to output a signal and work with Vulkan, OpenGL, etc. on a Pi.

See the linked GitHub issue for more details.
