AMD Radeon RX 7600
| CM4 Functionality | Pi 5 Functionality | Driver Required? | More Info |
|---|---|---|---|
| None | Currently Testing | Yes | GitHub Issue |
Videos Related to this Card
There are no videos for this card yet.
Description and Notes
The Radeon RX 9060 XT is a low-end graphics card supported by the open source amdgpu driver in the Linux Kernel.
It requires a 16x PCIe card slot. You will need to supply power to the card directly through a PCIe power plug.
amdgpu (open source) driver
To get the amdgpu driver loaded, you have to recompile the Linux kernel for Pi OS.
Go to Device Drivers > Graphics support on the menuconfig step, and select the amdgpu driver to install.
Also make sure you have the AMD firmware installed (sudo apt install -y firmware-amd-graphics) or the driver will complain about missing files.
On the Compute Module 4, it doesn’t seem we can get amdgpu drivers to work with the Pi’s PCIe bus.
On the Pi 5, we are currently testing Coreforge’s Pi OS Linux GPU support branch.
See the linked GitHub issue for more details.
